Machine application：
Silver-plated wire, tin-plated wire, nickel-plated wire,copper wire drawing and Continuous softening.
Main Technical Specification
Item
DT18
DT24
26DHA
Outlet diameter
φ0.25-φ0.7mm
φ0.08-φ0.25mm
φ0.1-φ0.45mm
Inlet diameter
φ0.8-φ1.65mm
φ0.5-φ1.0mm
φ0.8-φ1.6mm
Fixed speed diameter
φ206mm
φ 160 mm
φ208 mm
Drawing dies NO
Max 18
Max.24
Max.26
Drawing slip ratio
1.176
1.15
1.15
Max drawing speed
1800M/MIN
1800M/MIN
2500M/MIN
Main motor
18.5 KW (AC)
15 KW (AC)
18.5 KW (AC)
Take-up spool
φ300*φ215*290mm
φ400*φ215(φ270)*305mm
φ300*φ215*290mm
φ300*φ217*290mm (50KG）
Take-up motor
4KW (AC)
4KW (AC)
4KW (AC)
Total power installation
92KVA
50KVA
23KW
