Finished outer diameter:1mm-8mm Min insulation thickness:0.2mm output :70kg/h Speed : Max 200m/min
Suitable for the production of silicone insulation and sheathing materials of electronic wire,high temperature wire,power cord,data wire production.
2.specification
|
Model |
GF60 GF65 |
GF80 GF85 |
GF90 GF100 |
|
Pay-off Type |
Drivng Type |
Dual-Shaft Type |
Dual-Shaft Type |
|
Screw L/D Ratio |
12:1 |
12:1 |
12:1 |
|
Screw Rotation Speed (R.P.M) |
0~35 |
0~35 |
0~35 |
|
Extrusion(kg/h) |
70~80 |
85~90 |
120~180 |
|
Main Power(KW) |
11 |
15 |
15~35 |
|
Wire Dia(mm) |
0.8~6.0 |
2.0~12 |
3.0~20 |
|
Cooling Trough
|
20m Power:7kw/4m |
20m Power:3.5kw/2m |
20m Power:3.5kw/2m |
|
Haul-off Power(KW) |
2.2 |
4 |
4~5.5 |
|
Line Speed(m/min) |
0~200 |
0~200 |
0~200 |
|
Take-up Power(KW) |
2.2kw |
4kw |
5.5kw |
